Industrial VCB Panel

Get a Price/Quote

MOQ : 1 Unit

Industrial VCB Panel Specification

Protection Level
IP4X / IP5X

Control System
Electro-Mechanical Relay/PLC based

Features
Arc Fault Protection, Interlocking, Drawout/Fixed Type, Mimic Diagram, Compact Design

Connectivity Type
Wired (Copper/Aluminum Busbar)

Panel Type
Vacuum Circuit Breaker (VCB)

Operating Voltage
11kV / 33kV

Cover Material
Powder Coated Steel

Rated Operation Voltage
11kV / 33kV

Cabinet Material
CRCA Steel

Protection Class
Class II

Rated Insulation Voltage
12kV / 36kV

Thickness
2.0 - 3.0 mm

Components
VCB, CTs, PTs, Relays, MFM, Indication Lamps, Control Switches

Way
Single/Double/Multiple Feeder

Cooling System
Natural Air Cooled

Current Rating
630A, 1250A, 2000A, 2500A

Base Material
Mild Steel

Rated Current
630A / 1250A / 2000A / 2500A

Product Type
Indoor/Outdoor VCB Panel

Material
CRCA Sheet Steel

Surface Finish
Powder Coated

Standard
IS/IEC 62271-200

Surface Color
Light Grey / RAL 7035

Rated Voltage
11kV / 33kV

Frequency (MHz)
50 Hz

Maximum Output Current
Up to 2500A

Dimension (L*W*H)
Customizable as per requirement

Application
Power Distribution, Transformer Protection, Industrial Substations

IP Rating
IP4X/IP5X

Display Type
Analog/Digital Metering

Operation Mechanism
Spring Charged Motor Mechanism

Cable Entry
Bottom/Top Entry

Earthing Switch
Manual / Motorized

Busbar Material
Electrolytic Grade Copper / Aluminum

Secondary Terminal Block
Provided

Ambient Temperature Range
-10C to +55C

Rated Short Circuit Withstand
25kA / 31.5kA for 3 seconds

Auxiliary Voltage
110V / 220V AC or DC

Panel Mounting
Floor Mounted

Installation Type
Indoor / Outdoor

Degree of Protection
As per IEC 60529

Maintenance
Low Maintenance

Relay Type
Numerical / Electromechanical

Industrial VCB Panel Trade Information

Minimum Order Quantity
1 Unit

Payment Terms
Cash in Advance (CID)

Supply Ability
10 Units Per Month

Delivery Time
7 Days

Main Domestic Market
All India

About Industrial VCB Panel

Experience the sought-after Industrial VCB Panel, now available at a reduced price. This laureate panel offers exceptional value with its robust construction from electrolytic grade copper or aluminum busbars and CRCA sheet steel. Highly in demand for power distribution, transformer protection, and industrial substations, its low-maintenance design, spring-charged motor mechanism, and excellent arc fault protection ensure uninterrupted operation. Rated for up to 2500A output and a short circuit withstand of 31.5kA, it delivers outstanding reliability and safety for both indoor and outdoor installations. Built to international standards, it's an excellent choice for modern industrial needs.

Sophisticated Features and Versatile Applications

The Industrial VCB Panel boasts arc fault protection, interlocking mechanisms, and user-friendly mimic diagrams. With flexible options for current rating, feeder ways, and cable entry, it adapts seamlessly to power distribution, transformer protection, and industrial substations. Its robust construction allows installation in both challenging indoor and outdoor environments, making it ideal for a variety of heavy-duty electrical applications where reliability is critical.

Flexible Payment Terms and Prompt Delivery

We offer competitive payment terms tailored to client requirements, serving the main domestic markets across India. Quick dispatch and efficient logistics ensure your panel is shipped rapidly upon order confirmation. Clients can request samples to evaluate product suitability before bulk purchase, enhancing confidence and satisfaction with every order.

FAQ's of Industrial VCB Panel:

Q: How is the Industrial VCB Panel installed for maximum effectiveness?

A: The panel is floor mounted and can be set up for indoor or outdoor environments. Installation is customizable based on cable entry, current rating, and feeder configuration, ensuring optimal alignment with site-specific needs.

Q: What are the key benefits of using electrolytic grade copper or aluminum busbars in this panel?

A: Electrolytic grade copper or aluminum busbars offer superior conductivity, minimal energy loss, and enhanced durability, which increases the panel's reliability during high-load operations.

Q: Where can this VCB panel be commonly used?

A: It is most commonly used in industrial substations, power distribution centers, and for transformer protection in large manufacturing or processing plants.

Q: What protection features are included in the panel?

A: This VCB panel provides arc fault protection, robust interlocking systems, manual/motorized earthing switches, and a high-degree of ingress protection (IP4X/IP5X) complying with IEC 60529.

Q: How is product quality maintained during the manufacturing process?

A: The panels are manufactured in accordance with IS/IEC 62271-200 standards, utilizing first-rate CRCA sheet steel and powder coated surfaces, ensuring long lifespan and excellent performance.

Q: What support is available post-purchase?

A: We offer comprehensive after-sales support including guidance on installation, operation, and maintenance, along with the availability of spare parts and technical consultation when needed.
